MIQ/Blue PS
Technical data
6 - 1
ba76095e02
01/2013
6
Technical data
Note
General technical data on MIQ modules are given in the T
ECHNICAL
DATA
chapter of the IQ S
ENSOR
N
ET
system operating manual.
6.1
Electrical data
6.1.1
Operation without line power supply unit
6.1.2
Operation with line power supply unit
100 ... 240 V AC
operation
Nominal voltage
Max. 24 V DC via the IQ S
ENSOR
N
ET
(for
details, see chapter T
ECHNICAL
DATA
of the
IQ S
ENSOR
N
ET
system operating manual).
Power consumption
0.6 W
Supply
Nominal voltage:100 ... 240 V AC ± 10 %
Frequency:
50/60 Hz
according to DIN IEC 60038
Line power connection:2 pin, N and L
Line cross-section of mains connection:
Europe:
1.5 ... 4.0 mm
2
USA:
AWG 14 ... 12
Fuse rating on the operator side: max. 16 A
Power consumption
Approx. 12 W
Output voltage
Max. 24 VDC via the IQ S
ENSOR
N
ET
(for
details, see chapter T
ECHNICAL
DATA
of the
IQ S
ENSOR
N
ET
system operating manual).
