MIQ/Blue PS Installation
3 - 1 ba76095e02 01/2013
3 Installation
3.1 Scope of delivery
The scope of delivery of the MIQ/Blue PS module includes:
 MIQ/Blue PS
 Accessory set, including
– 4 x cable glands (clamping range 4.5-10 mm) with seals and blind
plugs
– 4x ISO blind nuts M4 with suitable socket head screws and plain
washers
– 2x countersunk screws M3x8 to close the module lid
(+ 2 spare ones)
– 1 x contact base with fixing screws
 Accessories for range test with attenuator
(see section 3.3)
– 1 x SMA attenuator VAT 10 dB
– 2 x reverse SMA adapters for SMA attenuator
 Operating manual.
3.2 Basic information on installation
3.2.1 General information
The MIQ/Blue PS radio modules are preconfigured in pairs and ready
for installation. Installation consists only of the connection to the
IQ S
ENSOR N ET .
Note
This chapter describes the installation of one radio link in the
IQ S
ENSOR N ET system. If several radio links should be installed, the
instructions in the appendix of this operating manual have to be fol-
lowed additionally.
Note
To prevent the radio transmission from being affected by water or snow
collecting on the antenna, we urgently recommend protecting any MIQ/
Blue PS radio modules against precipitation with the aid of a plastic
canopy (SSH/IQ).
