Commissioning
NiCaVis 705 IQ
3 - 12 ba75950e01 03/2013
3.4.4 Settings for virtual sensors
Carrying out settings Using , switch from the measured value display to the main menu
of the settings. Then navigate to the setting menu (setting table) of the
sensor. The procedure is described in detail in your IQ S
ENSOR
N
ET
system operating manual.
Default values are marked in bold.
Menu item Settings Explanations
Measuring mode
(NitraVis 705 IQ)

NO3-N

NO3
The measured parameter is displayed
in the selected citation form.
Measuring mode
(CarboVis 705 IQ)
 COD spectr., total
 COD spectr., dissolv

TOC spectr., correl.

BOD spectr., correl.

DOC spectr., correl.

SAC 254, total

SAC 254, dissolved
 UVT 254
The measured parameter is displayed
in the selected citation form.
Measuring location Outlet (permanently set) Measurement location or application of
the sensor.

The possible measurement loca-
tions are displayed depending on the
currently set measuring mode.
 The sample matrix on which the cal-
culation of the measured value is
based changes with the location of
the sensor.
Measuring range - Display of the measuring range
(see chapter 8 T
ECHNICAL DATA
).
Cal - # raw value 1 Value pairs of the user calibration (see section 4.3.2).
Note: Leave those values unchanged during the initial commission-
ing.
Cal - ref. value 1
Cal - # raw value 2
Cal - ref. value 2
