118

Omron Touch-Screen Display

Combo 1

Pump 1

Either Pump 1, 2, or 3 on the VFD

Same as above but with the pump with

Combo 2

Pumps 1& 2

Combo 3

Pumps 1, 2, & 3

the lowest hours set up as an
across-the-line lag pump
Same as above with the pump with the
highest hours set up as an
across-the-line lag pump.

Example 2: You have two 75 HP main pumps that can run on a VFD, or across-the-line. You
have two 60 HP main pumps that can run across-the-line only.
N61:0 is the first lead group. You would enter 6 for the first 2 pumps (2 + 4 from the table
above).
N61:1 is the second lead group. You would enter 24 for the pumps 3 and 4 (8 + 16 from the table
above).
In this example, you would set your combos according to the following table:

Combo 1

Pump 1

Either Pump 1 or 2 on the VFD

Either Pump 1 or 2 on the VFD with the

Combo 2

Pump 1& 2

non-VFD pump set to come on
across-the line pump

Combo 3

Pumps 1, 2, & 3

Same as above but with Pump 3 or 4 set

to come on across-the-line

Same as above but with the remaining

Combo 4

Pumps 1,2,3, & 4

pump set up as an across-the-line lag
pump

· Optionally, press the Main Menu touch key to return to the Main Menu. (See also,

Main Menu

· Optionally, press N Reg Menu to return to the previous screen,

N Register Access

screen.

· Optionally, press Combo Menu to return to open the Combo Menu screen.

2.20 Check If False Feedback or Individual Faults are Enabled

You can access the Accessories screen and define your filter parameters by pressing the Register
Access touch key on the

Main Menu

and opening the Register Access screen. The password

protected N99 Config and ID screen is accessed from the Register Access screen by pressing the N
Register Menu touch key.
