PAGE 16
Residential Water Systems
CentriPro
6-10" thrEE phaSE motorS
motor
hp kw Volts phase
f.l. kVa line - line time Delay fuse
order No. Efficiency % Code Resistance Standard Dual Element
6M058 5 3.7 200 75.9 K 0.618 50 25
6M052 5 3.7 230 76.8 K 0.806 45 20
6M054 5 3.7 460 76.8 K 3.050 25 10
6M078 7.5 5.5 200 77.9 J 0.504 80 40
6M072 7.5 5.5 230 78.5 J 0.651 70 30
6M074 7.5 5.5 460 78.5 J 2.430 35 15
6M108 10 7.5 200 79.7 K 0.315 100 50
6M102 10 7.5 230 79.3 K 0.448 90 40
6M104 10 7.5 460 79.3 K 1.619 45 20
6M158 15 11 200 81.7 K 0.213 175 70
6M152 15 11 230 81.7 K 0.312 150 60
6M154 15 11 460 81.7 K 1.074 70 30
6M208 20 15 200 82.7 J 0.189 200 90
6M202 20 15 230 83.2 J 0.258 175 70
6M204 20 15 460
3
83.2 J 0.861 90 35
6M258 25 18.5 200 82.0 K 0.146 250 110
6M252 25 18.5 230 83.0 K 0.210 225 90
6M254 25 18.5 460 83.0 K 0.666 110 45
6M308 30 22 200 82.9 J 0.119 300 125
6M302 30 22 230 82.5 K 0.166 250 100
6M304 30 22 460 82.5 K 0.554 125 50
6M404 40 30 460 84.0 H 0.446 175 70
66M504 50 37 460 82.5 J 0.388 225 90
86M504 50 37 460 83.8 K 0.331 225 125
86M604 60 45 460 86.3 J 0.278 250 150
8M754 75 55 460 84.9 H 0.218 300 125
8M1004 100 75 460 85.2 H 0.164 400 175
8M1254 125 90 460 84.2 G 0.132 500 225
8M1504 150 110 460 85.6 G 0.115 600 250
10M2004 200 150 460 87.2 F 0.0929 800 350
6" SINGlE phaSE motorS
motor
hp kw Volts phase
f.l. kVa resistance - ohms
order No. Efficiency % Code r - y b - y r - b
6M051 5 3.7 74.8 G 2.172 0.512 2.627
6M071 7.5 5.5
230 1
72.9 F 1.401 0.400 1.774
6M101 10 7.5 73.6 E 1.052 0.316 1.310
6M151 15 11 73.7 D 0.678 0.230 0.850
