Typical Characteristics
(Continued)
At T
A
= +25°C, V
IN
= V
OUT(TYP)
+ 0.3V, V
VCC
= 5V, I
OUT
= 50mA, V
EN
= V
IN
, C
IN
= 1µF, C
VCC
= 4.7µF, and C
OUT
= 10µF, unless otherwise noted.
Figure. 15 V
IN
Line Transient Figure. 16 V
VCC
Line Transient
Figure. 17 Output Load Transient Figure. 18 Turn-On Response
0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6
0.0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
2.0
Ivc
c
(m
A)
Iout(A)
-40 o C
25 o C 125 o C
Figure. 19 V
CC
Pin Current vs. I
OUT
and Temperature
2.0 2.4 2.8 3.2 3.6 4.0 4.4 4.8 5.2 5.6
0.0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
2.0
Ivcc(m
A)
Vvcc(V)
-40 o C
25 o C 125 o C
Figure. 20 V
CC
Pin Current vs. V
VCC
and Temperature
