AP7173
1.5A LOW DROPOUT LINEAR REGULATOR WITH
PROGRAMMABLE SOFT-START
AP7173
Document number: DS31369 Rev. 9 - 2
4 of 15
April 2011
© Diodes Incorporated
Absolute Maximum Ratings
(Note 4)
Symbol
Parameter
Ratings
Unit
ESD HBM
Human Body Model ESD Protection
4000
V
ESD MM
Machine Model ESD Protection
350
V
V
IN
, V
VCC
Input Voltage Range
-0.3 to +6
V
V
EN
Enable Voltage Range
-0.3 to +6
V
V
PG
Power-Good Voltage Range
-0.3 to +6
V
V
SS
Soft-Start Voltage Range
-0.3 to +6
V
V
FB
Feedback Voltage Range
-0.3 to +6
V
V
OUT
Output
Voltage
Range
-0.3 to V
IN
+0.3
V
I
OUT
Maximum Output Current Internally
Limited
P
D
Continuous Total Power
Dissipation (Note 5)
DFN3030-10 3690
mW
SO-8EP 5650
T
J
Junction Temperature Range
-40 to +150
ºC
T
ST
Storage Junction Temperature Range
-65 to +150
ºC
Notes:
4. Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These are stress ratings only
and functional operation of the device at these conditions is not implied. Exposure to absolute-maximum-rated conditions for extended periods
may affect device reliability.
5. Ratings apply to ambient temperature at 25°C . The JEDEC High-K board design used to derive this data was a 2 inch x 2 inch multilayer board
with 1-ounce internal power and ground planes and 2-ounce copper traces on the top and bottom of the board.
Recommended Operating Conditions
Symbol
Parameter
Min
Max
Unit
V
IN
Input Voltage (Note 6)
1.0
5.5
V
V
VCC
Bias Voltage
2.7
5.5
V
I
OUT
Output Current
0
1.5
A
T
A
Operating Ambient Temperature
-40
85
ºC
Note:
6. At V
IN
=1V, the maximum load currents may be lower than 1.5A.
