AP65550
Typical Performance Characteristics
(cont.)
(@T
A
= +25°C, V
IN
= 12V, V
OUT
= 1.05V, L = 1.5µH, C1 = 20µF, C2 = 44µF, unless otherwise specified.)
DCM Voltage Ripple 30mA
Time-1µs/div
Startup with VREG5 No Load
Time-1ms/div
EN (3V/DIV)
VREG5 (5V/DIV)
VOUT (500mV/DIV)
VOUT_AC (50mV/DIV)
SW (5V/DIV)
