Turn the switch to OFF.
Replace the cap(s) on the laser
output aperture(s).
Remove the battery.
Return the equipment and all ac-
cessories to the storage/carrying
carton.
4.2. OPERATOR TROUBLESHOOTING
The purpose of troubleshooting is to identify the most commonly occurring
equipment malfunctions, their probable causes, and the corrective actions
required to fix them.
Table 4-2 lists common malfunctions that may occur during the operation
or maintenance of the LAD. Perform the tests, inspections, and corrective
actions in the order listed in the table.
This table cannot list all of the malfunctions that may occur with your LAD,
or all of the tests and corrective actions that may be necessary. If you experi-
ence an equipment malfunction that is not listed, or is not fixed by the cor-
rective actions listed in the table, please contact the Customer Support.
TABLE 4-2. OPERATOR TROUBLESHOOTING
MALFUNCTION
PROBABLE CAUSE/ TEST/
INSPECTION
CORRECTIVE ACTION
LAD fails to activate
(no aiming dot, no IR
illumination).
Battery is dead, missing or
improperly installed.
Replace battery or
install it correctly.
Battery contact surfaces or
contact springs are dirty or
corroded.
Clean as per Part 4.3.2.
Laser diode is faulty.
Please contact the
Customer Support.
Boresight adjustment
screws do not adjust for
aiming dot position.
Adjustment mechanisms
are faulty.
Please contact the
Customer Support.
TABLE 4-1. CONTINUED
