17
TABLE 2-4. ELECTRICAL DATA
ITEM
DATA
DRAKOS DRAKOS-I DRAKOS-II
Battery
Single CR123A
Lithium (3V) or AA
Alkaline (1.5V)*
Single CR123A
Lithium (3V)**
Single CR123A
Lithium (3V) or AA
Alkaline (1.5V)*
Battery Life at 20°C/
68°F (hr, min)
42 2 27
* Any AA or CR123 type rechargeable batteries with voltage from 1.2V to 3.2V can
be used
** Any CR123 type rechargeable batteries with voltage 3.2V can be used
TABLE 2-5. ENVIRONMENTAL DATA
ITEM DATA
Operating Temperature -20 to +40°C (-4 to +104°F)
Storage Temperature - 40 to +55°C (-40 to +131°F)
Immersion 10m for 2 hr
2.3 STANDARD COMPONENTS
LAD standard components are shown in Figure 2-2 and listed in Table 2-6.
The ITEM NO. column indicates the number used to identify items in Figure
2-2.
FIGURE 2-2. STANDARD COMPONENTS
1 2 3 4
