28
TABLE 4-1. PREVENTIVE MAINTENANCE CHECKS AND SERVICES
SEQ
NO.
LOCATION/
ITEM TO
INSPECT/ CHECK/
SERVICE
PROCEDURE
NOT FULLY MISSION
CAPABLE IF...
BEFORE OPERATION CHECKS
1 Completeness
Inventory items by comparing
them with the data specified in this
manual.
Items are missing.
2 Body
Inspect for dirt, cracks, or damage.
Scratches and gouges are OK if
operation is not affected. Inspect
for missing parts (safety lock screw,
caps, etc.).
Clean as required.
Cracked or dam-
aged. Missing
parts.
3 Laser Aperture
Cap(s)
Inspect for dirt or damage. Inspect
for retainer breaks.
Clean as required.
Cap is damaged.
Retainer is broken.
4
Battery Com-
partment/ Cap
with Adapter
Verify that the battery adapter
and O-ring are present. Inspect for
corrosion, moisture, corroded or
defective contacts. Inspect for cap
damage or retaining loop breaks.
Inspect O-ring for cuts or damage.
Clean as required.
Contacts are dam-
aged or corroded.
Retaining loop
is broken. Cap,
O-ring or adapter
is damaged or
missing.
5 Adjustment
Screw Caps
Inspect for dirt, damage. Inspect for
retaining strap breaks.
Clean as required.
Caps are damaged.
Retaining strap is
broken.
6 Mode Select
Switch
Check for operation (without bat-
tery).
Switch is inopera-
tive.
7
Laser Aperture
Protective
Glass(es)
Inspect for cleanliness, scratches,
chips, or cracks.
Clean as required.
Scratches, chips or
cracks are present.
8 Remote Control
Unit
Check for damage.
Check Velcro tape for wear.
Damaged. Unit or
tape is missing.
9 Mount
Inspect for dirt, damage, corrosion,
or missing parts. Check for proper
operation.
Clean as required.
Mount is damaged.
Missing parts.
Clamping device is
inoperative.
