ITEM
NO.
CONTROL FUNCTION
4
5
Elevation
Adjustment
Screws
Windage
Adjustment
Screws
Adjust the laser(s) boresight.
NOTE:
When turning the screws, adjustment mechanisms
click in increments corresponding to the minimum
boresight correction value 0.5 mils (5cm at a
distance of 100m).
The circular scales are indexed in 0.5 mils adjustment
increments.
Elevation and windage adjustment ranges are cov-
ered in approximately 4 turns of the screws.
NOTE:
If using one of the two-channel devices, remember
that the screws adjust the boresight of both lasers
concurrently.
-
Remote Control
Button
Activates/deactivates the laser(s) in standby when
held down/released.
TABLE 3-2. OPERATION MODES
MODEL
OPERATING PARAMETERS
OFF
LOW-POWER OPERATION HIGH-POWER OPERATION
“LOW 1” “LOW 2” “HI 1” “HI 2”
DRAKOS Turned off
IR Dot
Level 1
0.1 mW
IR Dot
Level 2
0.2 mW
IR Dot
Level 3
0.3 mW
IR Dot
Level 4
0.7 mW
DRAKOS-I Turned off
IR Dot
Level 1
0.2 mW
IR Dot
Level 1
0.2 mW &
IR Illum
Level 1
125 mW
IR Dot
Level 2
0.9 mW
IR Dot
Level 2
0.9 mW &
IR Illum
Level 2
250 mW
DRAKOS-II Turned off
IR Dot
Level 1
0.1 mW
Red Dot
Level 1
0.3 mW
IR Dot
Level 2
0.6 mW
Red Dot
Level 2
0.9 mW
TABLE 3-1. CONTINUED
