2-20

Chapter 2: BIOS setup

CPU TM Function [Enabled]

Enables or disables Intel

®

CPU Thermal Monitor (TM) function, a CPU overheating

protection function. When enabled, the CPU core frequency and voltage are

reduced when the CPU overheats. Configuration options: [Disabled] [Enabled]

Execute-Disable Bit Capability [Enabled]

Allows you to enable or disable Intel

®

Execute Disable Bit Capability. This function

enhance protection of your computer, reducing exposure to viruses and malicious

buffer overflow attacks when working with its supporting software and system.

Configuration options: [Disabled] [Enabled]

Intel(R) SpeedStep(TM) Tech [Disabled]

Allows you to use the Enhanced Intel

®

SpeedStep

TM

Technology. When set to

[Enabled], you can adjust the system power settings in the operating system to

use the EIST feature. Set this item to [Disabled] if you do not want to use the EIST.

Configuration options: [Enabled] [Disabled]

The following item appears only when you installed an Intel

®

Pentium

®

4 or later

CPU that supports the Enhanced Intel SpeedStep

®

Technology (EIST).

Advanced

Configure System Frequency/Voltage

Current FSB Speed

1067MHz

Current Memory Speed

800MHz

Target Memory Speed

800MHz

System Clock Mode

[Auto]

iGPU OvereClock Mode

[Auto]

Memory Over voltage

[Auto]

Chipset Over voltage

[Auto]

CPU Voltage

[Auto]

Memory Timings

[Auto]

2.4.2

Jumperfree Configuration

[Auto] Set FSB & Memor

clock automatically.

[Linked] Allows Memory

and FSB to overclock

proportionally.

[Unlink] Enter FSB and

Memory clock manually.

[Profiled] Set FSB and

System Clock Mode [Auto]

Allows you to select the system clock mode. Configuration options: [Auto] [Linked]

[Unlinked] [Profiled]
