xi
(continued on the next page)
Wireless
Wi-Fi 802.11 a/b/g/n/ac supports dual frequency band 2.4/5 Ghz
Bluetooth v4.0/3.0+HS
* The module is pre-installed on the mPCIe Combo II expansion card.
Audio
ROG SupremeFX Impact 8-Channel High Definition
Audio*
- Lineout DAC playback Signal-to-Noise (A-weighted, differential
output): 115 dB
- Headphone DAC playback Signal-to-Noise Ratio (A-weighted,
differential output): 110 dB
- SupremeFX Shielding Technology
- ELNA ® Premium Audio Capacitors
- TI LM4562 high fidelity audio OP AMP
- Content Protection for Full Rate lossless DVD Audio, Blu-ray
DVD, and HD-DVD audio content playback
- Jack-detection, Multi-streaming, Front Panel Jack-retasking*
- Optical S/PDIF out port at back panel
Audio Feature:
- Sonic Radar
- DTS Connect
- Music PnP
* Jack-retasking supports 8-channel audio output using a chassis with
HD audio module in the front panel.
USB
Intel ® Z87 Express Chipset
6 x USB 3.0 ports (4 ports at back panel [blue], 2 ports at mid-board
[red]*)
6 x USB 2.0 ports (4 ports at back panel, 1 for ROG Connect; 2
ports at mid-board**)
* Supports ASUS USB 3.0 Boost. UASP standard on the Intel ® native
USB 3.0 is only supported under Windows ® 8.
** 2 x USB2.0 ports at mid-board share with ROG extension (ROG_EXT)
port.
Back I/O Ports
1 x Optical S/PDIF out
1 x HDMI port
1 x DisplayPort
1 x Clear CMOS button
1 x Q-Code LED
1 x DirectKey button
1 x MemOK! button
1 x ROG Connect button
4 x USB 2.0 ports
1 x eSATA port
4 x USB 3.0 ports [blue]
1 x LAN (RJ45) port
3 x Audio jacks
MAXIMUS VI IMPACT specifications summary
