3-18 Chapter 3: BIOS setup
Chapter 3
The following item appears only when you set the CPU Power Phase Control to [Manual
Adjustment].
Manual Adjustment [Fast]
Allows you to set a response for the CPU power phase control.
Configuration options: [Ultra Fast] [Fast] [Medium] [Regular]
CPU Power Duty Control [T.Probe]
CPU Power Duty Control adjusts the current of every VRM phase and the thermal
conditions of every phase component.
[T. Probe] Select to maintain the VRM thermal balance.
[Extreme] Select to maintain the current VRM balance.
DO NOT remove the thermal module. The thermal conditions should be monitored.
CPU Current Capability [Auto]
DIGI + VRM CPU Current Capability provides wider total power range for overclocking.
A higher value setting gets higher VRM power consumption delivery and extends the
overclocking frequency range simultaneously.
Configuration options: [Auto] [100%] [110%] [120%] [130%] [140%]
Choose a higher value when overclocking or under a high CPU loading for extra power
support.
CPU Power Thermal Control [130]
A higher temperature brings a wider CPU power thermal range and extends the
overclocking tolerance to enlarge the O.C. potential. Use the <+> and <-> keys to
adjust the value. The values range from 130 to 151.
DO NOT remove the thermal module. The thermal conditions should be monitored.
CPU Input Boot Voltage [Auto]
Set a VCCIN for the CPU right at boot. Use the <+> and <-> keys to adjust the value.
The values range from 0.00V to 2.440 with a 0.010V interval.
DRAM Current Capability [100%]
A higher value brings a wider total power range and extends the overclocking range
simultaneously.
Configuration options: [100%] [110%] [120%] [130%]
