Asus AP120-E1 User Manual
Page 47

3-9
ASUS AP120-E1 user guide
To hold long expansion cards:
1. Place the card holder at level with the expansion card.
The smaller card holder is for
long AGP cards while the
other card holders are for
long PCI cards.
2. Loosen the screw(s) to adjust the
card holder forward or sideward
until its groove fits the edge of the
expansion card.
3. Fasten the card holder screw(s).
4. Follow the same steps in holding
other long expansion.
2
3
