2-15

ASUS AP120-E1 user guide

2.7.2 Installing additional optical drive(s)

1. Select the drive bay you intend

to use. Push the knock down
metal cover in and out of the
chassis until it is removed.

2. Carefully insert the drive to the

bay, then push it inward until it
is flushed to the chassis front
panel.

3. Align the optical drive and bay

screw holes.

4. Secure the drive with two

screws on both sides of the
bay.

Screw holes

3

4

2

1

1

Configure your optical drive as Master/Slave device before installing it
to the drive bay. Refer to the optical drive documentation for details.

To install an additional optical drive(s):
