Chapter 2: Hardware setup

2-2

2.1

Preparation

Basic components to install

You need to install the following components to the AP120-E1
server/workstation.

1. Central processing unit (CPU)

2. Dual Inline Memory Module(s) (DIMMs)

3. Hard disk drive

4. 5.25-inch drive(s)

5. Expansion card(s)

Tool

You need a Philips (cross) screw driver to install some system components.

2.2

Removing the side cover

To remove the side cover:

2. Press the side cover locks

outward, then pull the side
cover toward the rear panel for
about one-half inch.

1. Locate the two side cover

locks.
