Data Sheet
QBVE060A0S10R4 Barracuda Series; DC-DC Converter Power Modules
45-56Vdc Input; 10.4Vdc, 60.0A, 625W Output
September 9, 2013 ©2012 General Electric Company. All rights reserved. Page 6
Characteristic Curves, 10.4V
dc
Output (continued)
The following figures provide typical characteristics for the QBVE060A0S10R4 (10.4V, 60A) at 25ºC. The figures are identical for
either positive or negative Remote On/Off logic.
OUTPU
T V
O
LT
A
G
E,
V
O
(V
)
OUTPU
T VOLT
AGE
, V
O
(V
)
INPUT VOLTAGE, V
in
(V) OUTPUT CURRENT, I
O
(A)
Figure 7. Typical Output Voltage Regulation vs. Input
Voltage.
Figure 8. Typical Output Voltage Regulation vs. Output
Current.
OUTP
UT VOL
TAG
E, V
O
(V)
OUTP
UT VOL
TAG
E, V
O
(V
)
INPUT VOLTAGE, V
in
(V) OUTPUT CURRENT, I
O
(A)
Figure 9. Typical Output Voltage Regulation vs. Input
Voltage for the –P Version. Figure 10. Typical Output Voltage Regulation vs. Output
Current for the –P Version.
.
