-10-
AF-300C11
HP Rating Enclosure
Rated
Output
Current
(A)
Overload
(150%
1min.)
AF-300C11
Model No. Catalog No.
Dimensions
H x W x D
(inches)
Weight
(lbs)
230VAC, 3 phase, 50/60Hz Input
1/8 IP20 0.7 1.1 6KC1123F12X1 * * D5674 4.72 x 3.15 x 3.23 1.3
1/4 IP20 1.4 2.1 6KC1123F25X1 * * D5675 4.72 x 3.15 x 3.43 1.3
1/2 IP20 2.5 3.8 6KC1123F50X1 * * D5676 4.72 x 3.15 x 3.82 1.5
1 IP20 4 6.0 6KC1123001X1 * * D5677 4.72 x 3.15 x 4.80 1.8
2 IP20 7 11 6KC1123002X1 * * D5678 5.12 x 4.33 x 5.55 3.3
3 IP20 10 15 6KC1123003X1 * * D5679 5.12 x 4.33 x 5.55 3.3
5 IP20 16.5 25 6KC1123005X1 * * D5680 7.09 x 5.51 x 5.47 4.9
230VAC, Single phase, 50/60Hz Input
1/8 IP20 0.7 1.1 6KC1121F12X1 * * D5668 4.72 x 3.15 x 3.23 1.3
1/4 IP20 1.4 2.1 6KC1121F25X1 * * D5669 4.72 x 3.15 x 3.43 1.3
1/2 IP20 2.5 3.8 6KC1121F50X1 * * D5670 4.72 x 3.15 x 4.61 1.5
1 IP20 4 6.0 6KC1121001X1 * * D5671 4.72 x 3.15 x 5.59 2.0
2 IP20 7 11 6KC1121002X1 * * D5672 5.12 x 4.33 x 5.94 3.5
3 IP20 10 15 6KC1121003X1 * * D5673 7.09 x 5.51 x 5.47 4.9
* * Indicates product revision
