11
FVR-C9S-7UX
3.86 (98)
2 - dia. 0.20
(2 - dia. 5)
0.24 (6.2)
0.18 (4.5)
0.24 (6.2)
DWG 2: FVR002C9S-7UX
0.24 (6)
0.45 (11.5)
TERMINAL M3.5
D1
0.24 (6.2)
0.24 (6.2) D
D2
0.24 (6.2)
4.65 (118) 4.21 (107)
4.33 (110)
5.12 (130)
0.20 (5)
1.97 (50)
3.15 (80)
0.24 (6.2)
0.45 (11.5)
0.45 (11.5)
0.43 (11)
3.43 (87)
0.45 (11.5)
Rated Current External Dimensions: inches (mm) DWG No.
Type [A] D D1 D2
FVR002C9S-7UX 6.4 5.53 (140.5) 3.05 (77.5) 2.56 (65) DWG 2
7-'005
