GE
Data Sheet
SHHD005A0F Hammerhead Series; DC-DC Converter Power Modules
18-75Vdc Input; 3.3Vdc, 5A, 15W Output
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243
, or +1 972 244 9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.878067-280
India:
+91.80.28411633
www.ge.com/powerelectronics
June 26, 2013
©2012 General Electric Company. All rights reserved.
Version 1.04
Ordering Information
Please contact your GE Sales Representative for pricing, availability and optional features.
Device Codes
Device Code
Input
Voltage Range
Output
Current
Output
Voltage
Remote
On/Off Logic
Connector
Type
Comcode
SHHD005A0F4Z
24V/48V (18-75Vdc)
5.0A
3.3V
Positive
Through hole
150024949
SHHD005A0F41Z
24V/48V (18-75Vdc)
5.0A
3.3V
Negative
Through hole
CC109172920
SHHD005A0F641-35Z
24V/48V (18-75Vdc)
5.0A
3.3V
Negative
Through hole
150032199
SHHD005A0F41-SRZ
24V/48V (18-75Vdc)
5.0A
3.3V
Negative
Surface mount
150023384
