GE Industrial Solutions KNW013-020 (Sixteenth-Brick) - Manual (Page 17)

Data Sheet
August 22, 2011
KNW013-020 Series Power Modules; DC-DC Converters
36 – 75V
dc
Input; 3.3 to 5.0V
dc
Output; 13 to 20A Output Current
Document No: DS08-009 ver. 1.05
PDF name: knw013-020_ds.pdf
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 1. Device Code
Product Codes Input Voltage
Output
Voltage
Output
Current
On/Off Logic
Connector
Type
Comcode
KNW013A0A4-SRZ 48V (36-75Vdc) 5.0V 13A Negative Surface mount CC109167128
KNW013A0A41-SRZ 48V (36-75Vdc) 5.0V 13A Negative Surface mount CC109141438
KNW013A0A41Z 48V (36-75Vdc) 5.0V 13A Negative Through hole CC109141446
KNW013A0A641Z 48V (36-75Vdc) 5.0V 13A Negative Through hole CC109156948
KNW013A0A841Z 48V (36-75Vdc) 5.0V 13A Negative Through hole CC109160207
KNW020A0F1-SRZ 48V (36-75Vdc) 3.3V 20A Negative Surface mount CC109172292
KNW020A0F41-SRZ 48V (36-75Vdc) 3.3V 20A Negative Surface mount CC109139267
KNW020A0F41Z 48V (36-75Vdc) 3.3V 20A Negative Through hole CC109139275
KNW020A0F641Z 48V (36-75Vdc) 3.3V 20A Negative Through hole CC109155727
KNW020A0F841Z 48V (36-75Vdc) 3.3V 20A Negative Through hole CC109167350
Table 2. Device Coding Scheme and Options
Characteristic Definition
Form Factor K K = Sixteenth Brick
Family Designator N
Input Voltage W W = Wide Range, 36V-75V
013A0 013A0 = 0 13.0 Amps Maximum Output Current
020A0 020A0 = 0 20.0 Amps Maximum Output Current
A A = 5.0V nominal
F F = 3.3V nominal
Omit = Default Pin Length shown in Mechanical Outline Figures
6 6 = Pin Length: 3.68 mm ± 0.25mm , (0.145 in. ± 0.010 in.)
8 8 = Pin Length: 2.79 mm ± 0.25mm , (0.110 in. ± 0.010 in.)
Omit = Latching Mode
4 4 = Auto-restart following shutdown (Overcurrent/Overvoltage)
Omit = Positive Logic
1 1 = Negative Logic
Omit = Standard open Frame Module
SR SR = Surface mount connections & tape/reel package
Customer Specific XY XY = Customer Specific Modified Code, Omit for Standard Code
Omit = RoHS 5/6, Lead Based Solder Used
Z Z = RoHS 6/6 Compliant, Lead free
RoHS
Ra
ti
n
g
s
Mechanical Features
O
p
ti
ons
Character and Position
Pin Length
Action following
Protective Shutdown
On/Off Logic
Output Current
Output Voltage
