Data Sheet
12A Digital PicoDLynx TM : Non-Isolated DC-DC Power Modules
3Vdc –14.4Vdc input; 0.45Vdc to 5.5Vdc output; 12A Output Current
Contact Us
For more information, call us at
USA/Canada:
+1 888 546 3243 , or +1 972 244 9288
Asia-Pacific:
+86.021.54279977*808
Europe, Middle-East and Africa:
+49.89.74423-206
India:
+91.80.28411633
www.ge.com/powerelectronics
November 19, 2013
©2013 General Electric Corporation. All rights
reserved.
Version 1.10
Ordering Information
Please contact your GE Sales Representative for pricing, availability and optional features.
Table 9. Device Codes
Device Code
Input
Voltage Range
Output
Voltage
Output
Current
On/Off
Logic
Sequencing Comcodes
PDT012A0X3-SRZ 3 – 14.4Vdc 0.45 – 5.5Vdc 12A Negative Yes CC109159661
PDT012A0X3-SRDZ 3 – 14.4Vdc 0.45 – 5.5Vdc 12A Negative Yes CC109168836
PDT012A0X43-SRZ 3 – 14.4Vdc 0.45 – 5.5Vdc 12A Positive Yes CC109159678
PDT012A0X43-SRDZ 3 – 14.4Vdc 0.45 – 5.5Vdc 12A Positive Yes CC109168844
-Z refers to RoHS compliant parts
Table 10. Coding Scheme
GE Digital Non-Isolated DC-DC products use technology licensed from Power-One, protected by US patents: US20040246754, US2004090219A1, US2004093533A1, US2004123164A1,
US2004123167A1, US2004178780A1, US2004179382A1, US20050200344, US20050223252, US2005289373A1, US20060061214, US2006015616A1, US20060174145, US20070226526,
US20070234095, US20070240000, US20080052551, US20080072080, US20080186006, US6741099, US6788036, US6936999, US6949916, US7000125, US7049798, US7068021, US7080265,
US7249267, US7266709, US7315156, US7372682,
US7373527, US7394445, US7456617, US7459892, US7493504, US7526660.
Outside the US the Power-One licensed technology is protected by patents: AU3287379AA, AU3287437AA, AU3290643AA, AU3291357AA, CN10371856C, CN1045261OC, CN10458656C,
CN10459360C, CN10465848C, CN11069332A, CN11124619A, CN11346682A, CN1685299A, CN1685459A, CN1685582A, CN1685583A, CN1698023A, CN1802619A, EP1561156A1, EP1561268A2,
EP1576710A1, EP1576711A1, EP1604254A4, EP1604264A4, EP1714369A2, EP1745536A4, EP1769382A4, EP1899789A2, EP1984801A2, W004044718A1, W004045042A3, W004045042C1,
W004062061 A1, W004062062A1, W004070780A3, W004084390A3, W004084391A3, W005079227A3, W005081771A3, W006019569A3, W02007001584A3, W02007094935A3
Package
Identifier
Family Sequencing
Option
Output
current
Output
voltage
On/Off
logic
Remote
Sense Options
ROHS Compliance
P D T 012A0 X 3 -SR -D Z
P=Pico
U=Micro
M=Mega
G=Giga
D=Dlynx
Digital
V =
DLynx
Analog.
T=with EZ
Sequence
X=without
sequencing
12A X =
programm
able output
4 =
positive
No entry
=
negative
3 =
Remote
Sense
S =
Surface
Mount
R =
Tape &
Reel
D = 105°C
operating
ambient,
40G
operating
shock as
per MIL Std
810F
Z = ROHS6
