Data Sheet SLI Inverters
February 2010 High-Efficiency, Low-Profile 1500 VA Inverters
Specifications
Electrical
Input Voltage 48 VDC (40-72 VDC) or 24 VDC (20-36 VDC)
Output Voltage 115 VAC (100-120 VAC) or 230 VAC (200-240 VAC) - select 115 or 230 VAC
model
Output Power 1500 W
Output Waveform True sine wave
Frequency 50/60 Hz (47-63 Hz) - select 50 or 60 Hz model
Frequency (Stability) ±0.02% maximum
Inverter Technology Pulse Width Modulation /High Frequency Switching
Dielectric Strength 2,500 VAC minimum
Inrush Current <10 A
Operating Modes On-line (standard); Standby (selectable)
Efficiency peak efficiency 93%
Output Power Factor 0.33 lagging or leading
Total Harmonic Distortion 2% maximum for linear loads /<3% for non-linear loads
DC Noise Feedback < 30 dBrnc
Transient Response <3% voltage change on instantaneous 0 to 100% load change
Transfer Time (With Static Switch) < 2 msec
Overload Capacity up to 125% continuous; 125% to 150% - 1800 cycles, 150% to 220% - 24
cycles, 220% to 300% - 4 cycles
Load Voltage Regulation +3%/-1%
Communications RS-485 or CANBUS communications interface and photo alarm relay
Display 2 x 20 LCD display (optional) with LED status bar
Input Overvoltage Protection 48 Vdc models: 74V; 24 Vdc Models: 37V
Input Undervoltage Protection 48 Vdc models: 36V; 24 Vdc Models: 18V
Input Overcurrent Protection 48 Vdc models: 70A; 24 Vdc models: 140A
Overload 230 Vac models: 1800 VA; 115 Vac Models: 1650 VA
Surge Capacity 230 Vac models: 2300 VA for 200 ms; 115 Vac Models: 1750 VA for 200 ms
Electronic Overcurrent Protection 230 Vac Models: 1A to 8A (selectable); 115 VAC Models: 2A to 15A (selectable)
AC Circuit Breaker 230 Vac Models: 10A; 115 Vac Models: 15A
Electronic Short-circuit Protection: 230 Vac Models: 30A; 115 Vac Models: 60A
Protection Mode
Progammable for "latch" or "auto restart" after incident
Isolation PRI-SEC: 3000 Vrms PRI-GND: 1000 Vrms SEC-GND: 1500 Vrms Signal-GND: 0
Vrms
MTBF 200,000 hours at 40°C
