July 11, 2011 Naos Raptor 40A Non Isolated Power Module:
5 – 13.8Vdc input; 0.6Vdc to 5.0Vdc Output; 40A output current
LINEAGE POWER 18
Document No: DS06-128 ver. 1.15
PDF name: NSR040A0X_ds.pdf
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 4. Device Codes
Device Code
Input
Voltage Range
Output
Voltage
Output
Current
On/Off
Logic
Connector Type Comcode
NSR040A0X43Z 5 – 13.8Vdc 0.6 – 5.0Vdc 40 A Positive SIP CC109130928
Table 5. Coding Scheme
Series
generation
Output
Current
Output
voltage
Pin Length On/Off
logic
Sense Default On/Off
Condition
ROHS
Compliance
NSR 040A0 X 4 3 Z
040A0=40A X =
programmable
output
Blank =
Standard
5=5.1mm
6=3.7mm
8=2.8mm
4 = positive
No entry =
negative
3 = Remote
Sense
Blank=without Blank=Standard,
ON when
unconnected
2=Inverted On/Off
Z = ROHS6
