Data Sheet
October 5, 2009

Naos

NXA025 SMT Non-isolated Power Modules:

10 – 14Vdc Input; 0.8Vdc to 5.5Vdc Output; 25A output current

LINEAGE

POWER

Document No: DS03-030 ver. 1.43

PDF name: nxa025_smt_ds.pdf

Ordering Information

Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 2. Device Codes

Product codes

Input

Voltage

Output Voltage

Output

Current

Efficiency

3.3V @ 25A

Connector

Type

Comcodes

NXA025A0X-S

10 – 14 Vdc

0.8Vdc – 5.5Vdc

25 A

93 %

SMT

108975053

NXA025A0X-HS

10 – 14 Vdc

0.8Vdc – 5.5Vdc

25 A

93 %

SMT

108975061

NXA025A0X-L

10 – 14 Vdc

0.8Vdc – 5.5Vdc

25 A

93 %

108988515

NXA025A0X-LP

10 – 14 Vdc

0.8Vdc – 5.5Vdc

25 A

93 %

CC109101350

NXA025A0X-SP

10 – 14 Vdc

0.8Vdc – 5.5Vdc

25 A

93 %

SMT

CC109101342

NXA025A0X-LPZ

10 – 14 Vdc

0.8Vdc – 5.5Vdc

25 A

93 %

CC109106746

NXA025A0X-SZ

10 – 14 Vdc

0.8Vdc – 5.5Vdc

25 A

93 %

SMT

109100402

NXA025A0X-HSZ

10 – 14 Vdc

0.8Vdc – 5.5Vdc

25 A

93 %

SMT

109100393

NXA025A0X-LZ

10 – 14 Vdc

0.8Vdc – 5.5Vdc

25 A

93 %

CC109107174

NXA025A0X-SPZ

10 – 14 Vdc

0.8Vdc – 5.5Vdc

25 A

93 %

SMT

CC109133682

-Z refers to RoHS-compliant versions.
