ACE3000T
3 Bay / 9 Kilowatt Power Shelf
Outline Drawing
PART NUMBER DEFINITION GUIDE
5.18
(131.6)
Series
3=3kW x 3 Bays
9kW Total
Power Blank=Non-Compliant
Y0=5 of 6 Compliant
Z0=6 of 6 Compliant
RoHS Compliance
Rev.
0 = 1Ш
3 = 3Ш
Input Phase
3 = 3 Slots
Output V
Blank = Front End
T = Rectifier
Type
Blank = Positive
N = Negative
Polarity
Blank = Bus Bar
H = Positronic
(front-end only)
Backplane Connector
ACE 3 x 3 x x x xx - 1A
RTN V1
L1 L2 L3
- +
L1 L2 L3
RTN
V1
ALL TELECOM SHELVES FRONT END POWER SHELVES (POSITIVE POLARITY)
FRONT END POWER SHELVES (NEGATIVE POLARITY)
16.00
(406.4)
16.00
(406.4)
17.165
(436)
17.165
(436)
5.18
(131.6)
5.18
(131.6)
3-Phase Input
Connector
V1
V1 RETURN
5.18
(131.6)
Series
3=3kW x 3 Bays
9kW Total
Power Blank=Non-Compliant
Y0=5 of 6 Compliant
Z0=6 of 6 Compliant
RoHS Compliance
Rev.
0 = 1Ш
3 = 3Ш
Input Phase
3 = 3 Slots
Output V
Blank = Front End
T = Rectifier
Type
Blank = Positive
N = Negative
Polarity
Blank = Bus Bar
H = Positronic
(front-end only)
Backplane Connector
ACE 3 x 3 x x x xx - 1A
RTN V1
L1 L2 L3
- +
L1 L2 L3
RTN
V1
ALL TELECOM SHELVES FRONT END POWER SHELVES (POSITIVE POLARITY)
FRONT END POWER SHELVES (NEGATIVE POLARITY)
16.00
(406.4)
16.00
(406.4)
17.165
(436)
17.165
(436)
5.18
(131.6)
5.18
(131.6)
3-Phase Input
Connector
V1
V1 RETURN
J4 FUNCTION
1 IOUT 1
2 IOUT 1 (Rs)
3 VPROG 1
4 VPROG 1 (Rs)
5 I-shARE 1
6 AlARM 1
7 GROUND 1 (Rs)
8 ON/OFF 1
J6 FUNCTION
1 IOUT 3
2 IOUT 3 (Rs)
3 VPROG 3
4 VPROG 3 (Rs)
5 I-shARE 3
6 AlArm 3
7 Ground 3 (rS)
8 on/oFF 3
J5 FUNCTION
1 IOUT 2
2 IOUT 2 (Rs)
3 VPROG 2
4 VPROG 2 (Rs)
5 I-shARE 2
6 AlARM 2
7 GROUND 2 (Rs)
8 ON/OFF 2
J4 / J5 / J6 are RJ45 Receptacle
AMP Part Number 55162-1
Example Part Numbers:
Backplane
Part # Type Phase Polarity Connector
ACE303T Rectifier single Positive Bus Bar
ACE333T Rectifier Three Positive Bus Bar
ACE303TN Rectifier single Negative Bus Bar
ACE333TN Rectifier Three Negative Bus Bar
3-Phase Input shelves
Use 3-Position Terminal
Blocks (Consult Factory
for Outline Drawing)
