DEH40913 Installation Instructions
g
Record Plus
TM
Molded Case Circuit Breaker
Accessories
Rotary Handle Operator, Type
THCH45.
Congratulations and thank you for choosing the
Record Plus™
family of circuit breakers and Rotary
Handle THCH45 Operator accessory kit for FC100
circuit breaker series in NEMA 4 and 4X enclosures.
Record Plus™
circuit breakers are designed with a
full line of integrated accessories. All units use the
latest integrated module circuit breaker technology
to allow flexibility in applications and maximizing
the product utilization and capabilities.
Figure 1a. FCNRM2
(Shallow Door Mount)
All
Record Plus
™ circuit breakers are listed by
Underwriters Laboratories to the UL489 standard
and the CSA Standard C22.2, No. 5. These circuit
breakers are certified to EN 60947-2.
These accessories are also for use with our MAG-
BREAK® instantaneous trip-only circuit breakers,
which meet the same standards and are UL-
recognized components for use in motor
applications. They can also be used with our molded
case switches, which are listed per Underwriters
Laboratories to the UL489 standard.
Figure 1b. FCNRM4
(Extended Shaft Door Mount)
Record Plus™
circuit breakers and their accessories
are designed and manufactured to exceed our global
customers’ high standards for reliability and quality.
Figure1. FCNRM2 & FCNRM4 with THCH45 Handle mounted
on Record Plus™ FC100 Circuit Breaker.
Warning: DANGER of Electrical shock or injury.
Ensure ALL electrical power supplies are OFF before
installing or removing any devices. The breaker, trip
unit or accessories MUST ONLY be installed and
serviced by QUALIFIED personnel, see NEMA
publication AB4.
Avertissement: Danger contre les risques
d'électrocutions. S'assurer avant TOUTES
manipulations du disjoncteur que les différentes
sources d'alimentation sont en position OFF. Les
disjoncteurs, unités de protection, ou accessoires
doivent être installés par des personnes qualifiées et
habilitées. Lira NEMA publication AB4.
CAUTION:
This product is NOT suitable for
use in equipment not specifically design to
accept it. Contact the equipment
manufacturer for possible equipment
modifications.
ATTENTION:
Cet appareil nedoit pas etre
employe dans un equipement non
specialement adapte a cet effet. Contactez le
constructeur concernant les possibles
modifications a apporter a l'equipement.
