Breakmaster load interrupter switch – GE Industrial Solutions BreakMaster Load Interrupter Switch User Manual
Page 6
5
Section 3 – Feature Identification
3.0
Front View with Top Door Open
3.2
Side View with Covers Removed
3.1
Front View with Lower Door Open
Louvers –
Front and
Rear
Switch
Mechanism
Safety Mechanical
Interlock
Oversize
Inspection
Window
Top Door
Lifting Angles Provided
on All Sections
Louvers –
Front and
Rear
Highly Visible
Warning SIgn
Lower
Door
Oversize
Inspection
Window
Safety Mechanical
Interlock
Lower Fuse
Compartment
Ground Bus
Data Label
Key Interlock
(when required)
Data Label
Glass Polyester
Insulators
Porcelain Available
as an option
Full Height
Phase Barrier
Large Cable
Pulling Space
Ground Bus
Copper Bus Standard
Switch Mechanism
Rigid Bolted Frame
Construction
Heavy-duty
Chain Drive
All Covers 11 Gauge Steel
Tough Polyester
Paint 2-mil Baked
Coating Thickness
BreakMaster Load Interrupter Switch
