October 1, 2009 Austin Lynx TM II 12V SIP Non-isolated Power Modules:
8.3 – 14Vdc input; 0.75Vdc to 5.5Vdc Output; 10A output current
LINEAGE POWER 19
Document No: DS04-023 ver. 1.25
PDF name: lynx_II_sip_12v_ds.pdf
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 2. Device Codes
Device Code
Input
Voltage
Range
Output
Voltage
Output
Current
Efficiency
3.3V@ 10A
On/Off
Logic
Connector
Type
Comcodes
ATA010A0X3 8.3 – 14Vdc 0.75 – 5.5Vdc 10 A 93.0% Negative SIP 108989050
ATA010A0X43 8.3 – 14Vdc 0.75 – 5.5Vdc 10 A 93.0% Positive SIP 108989067
ATA010A0X3Z 8.3 – 14Vdc 0.75 – 5.5Vdc 10 A 93.0% Negative SIP CC109104667
ATA010A0X43Z 8.3 – 14Vdc 0.75 – 5.5Vdc 10 A 93.0% Positive SIP CC109104683
-Z refers to RoHS compliant codes
