GE Industrial Solutions A-Series II Panelboards THQB - Manual

DEH40158
DEH40158 Rev.No.01 1
g
A-Series
®
II Panelboards
AD/AE/AQ Type P & N Panel
THQB Three-Phase Circuit
Breaker Kits
Introduction
These instructions describe the installation of THQB three-phase circuit breaker kit into
an A-Series
®
II panelboard. These kits are for use in panelboards ordered with Un-
Specified Space.
The catalog number for 6-pole THQB breaker kit is ASPP6QB6D
Parts List ASPP6QB6D Table 1
ITEM # DESCRIPTION PART # QTY
1 A & C PHASE 200A STRAP 315A7049P10 2
2 STRAP, CENTER 315A7048P20 1
3 3X BRANCH BASE 911E347P3 1
4 THREAD ROLLING SCREW & WASHER 315A7034P6 3
5 FILLER PLATE, QB 139C5362P2 1
6 SCREWS , #10-32 X 3/8 N722P16006B6 4
Table 1. Parts list for THQB three-phase, twelve-pole breaker installation kit, and
catalog number ASPP6QB6D.
Installation
WARNING: Before attempting to install one of these kits, remove all power from the
panelboard.
Use the following procedure to install a THQB circuit breaker kit. Call-out numbers in
the illustrations and numbers in brackets in the text refer to the Item Numbers in Table 1.
Installation of a three-pole kit is illustrated in Figure 1.
1. Remove the interior assembly from its packaging and verify that all parts are
present, as given in the packing list.
2. Remove the 8 screws (600A and 800A panels) securing the dead front to
panelboard interior. Lift off the dead front and place it and the screws aside.
3. Remove the circuit breaker kit from its packaging and verify that all parts are
present, as given in the packing list.
4. Refer fig no.1 to mount the breaker on interior. Place 3X base [3] adjacent to the
crossbar [7], to locate the mounting hole for the B phase strap [2]. Remove 3X
base [3] and screw the B phase strap [2] into place using screw [4]. Then mount
the strap for A and C phase [1] into place using screws [4]. All phase straps
