11
Alarm Relay
The Compact Event Log (CEL) has control of the Alarm
Output (BO68). The alarm values in the Alarm Output
tab classify what events will trigger the Alarm Output. The
enabling Device Statuses alarm when a reset, dead battery,
device offline, or undervoltage event occurs. Time Change
alarms when a Time Change event occurs. Lighting
Statuses alarm when a Status On or a Status Off event
occurs. Lighting Alarms alarm when a Command Failure,
or a Breaker Tripped event occurs. The Alarm Values
option can be edited will the LCD Programmer. The
Alarm Relay object is listed in Table 12.
Description Type
BACNet
Object
Modbus
Register
Alarm relay — BO68 Fn 1/5/15, 068
Table 12. Alarm Relay object and corresponding BACNet object and Modbus
register values.
Load Shedding
The Load Shedding (LS) object contains a list of objects
that can be shed. Each object has a Shed Level assigned to
it. The Shed Level defines what objects are deactivated at
a given Shed Level. The Shed Level (a value from 0–5) is
written to the Lighting Controller from a Power
Management device. The Load Shedding object is listed
in Table 13.
Device Information
The Device Information object displays the items listed in
Table 14.
Regional Settings
The Regional Setting (RS) object contains a list of cities
and the predefined longitude, latitude, daylight savings
time (DST) information and Universal Time coordinates
(UTC) offset for each. Selecting a given city with the LCD
Programmer applies the location settings for the given city
to the device. Latitude, longitude, DST, and UTC offset
can be edited individually with the LCD Programmer.
The Regional Setting object is listed in Table 15.
Description Type BACNet Object Modbus Register
Load shedding
• Present Value
• Shed Level (0–5)
• Shed Duration (minutes) RO
RW
RW
LS1
• PresentValue
• ShedLevel
• ShedDuration
Fn 3/6/16, 30001–30003
Table 13. Load Shedding object and corresponding BACNet object and Modbus register values.
Description Type BACNet Object Modbus Register
Device Information
• Firmware version
• Hardware version
• Major software version
• Last reset time and date
• Current time and date RO
RO
RO
RO
RO
DEVx
• FirmwareVersion
• HardwareVersion
• AppSwVersion
• LastResetTime
• CurrentTime
Fn 4, 10001–10046
• 10001–10007
• 10008–10014
• 10015–10021
• 10029–10032
• 10033–10038
Table 14. Device Information object and corresponding BACNet object and Modbus register values.
Description Type BACNet Object Modbus Register
Controller Geographic Location
• Latitude
• Longitude RW
RW
DEVx
• Latitude
• Longitude
Fn 4,
• 10022–10023
• 10024–10025
Table 15. Load Shedding object and corresponding BACNet object and Modbus register values.
