A synopsis of the C-2000 line's broad scope
Standards and Listings IEC 947-1 BS 5424 CSA C.22.2/14
IEC 947-4 BS 775 EN 50005
IEC 158-1 CEI 17-3/252 UNE 20109
CENELEC HD 419 ASE 1025 VDE 0660/102
NFC.63-110 UL 508 CE Mark
Pending Standards SEMKO, NEMKO, DEMKO, Lloyds Register
and Listings
Ambient Temperature
Operating -13˚ to +131˚F / -25˚ to +55˚C
Storage -58˚ to +176˚F / -50˚ to +80˚C
Altitude Derating
Up to 10,000 ft. Nominal Values
(3,000 m)
10,000 to 13,200 ft. 90% rated current
(3,000 to 4,000 m)
13,200 to 16,000 ft. 80% rated current
(4,000 to 5,000 m)
Maximum Rated Voltage 600 VAC
Mounting Position
3-Pole and 4-Pole To maintain operating integrity, the contactor must be mounted in one of the
CL Contactors positions shown below:
(5-75 hp)
3-Pole and 4-Pole The contactor must be installed vertically or tilted a maximum of 30˚ from vertical,
CK Contactors as shown below:
(100-500 hp)
General Specifications
