September 10, 2013 Austin Lynx TM SMT Non-isolated Power Modules:
3.0 – 5.5Vdc Input; 0.75Vdc to 3.63Vdc Output; 10A output current
LINEAGE POWER 20
Document No: DS04-031 ver. 1.56
PDF name: lynx_po_smt.pdf
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 2. Device Codes
Device Code
Input
Voltage
Range
Output
Voltage
Output
Current
Efficiency
3.3V@ 10A
Connector
Type
Comcodes
AXH010A0X-SR 3.0 – 5.5Vdc 0.75 – 3.63Vdc 10 A 95.0% SMT 108992021
AXH010A0X-SRZ 3.0 – 5.5Vdc 0.75 – 3.63Vdc 10 A 95.0% SMT CC109104948
AXH010A0X3-SR* 3.0 – 5.5Vdc 0.75 – 3.63Vdc 10 A 95.0% SMT 108992038
AXH010A0X3-SRZ* 3.0 – 5.5Vdc 0.75 – 3.63Vdc 10 A 95.0% SMT CC109104931
* Remote sense feature is active and pin 6 is added with code suffix “3”
* -Z refers to RoHS-compliant versions.
