EHW015A0A Series Eighth-Brick Power Modules
36–75Vdc Input; 5.0Vdc Output; 15A Output Current
Document No: DS08-003 ver. 1.02
PDF name: ehw015_ds.pdf
World Wide Headquarters
Lineage Power Corporation
601 Shiloh Road, Plano, TX 75074, USA
+1-800-526-7819
(Outside U.S.A.: +1-972-244-9428)
www.lineagepower.com
e-mail: [email protected]
Asia-Pacific Headquarters
Tel: +65 6593 7211
Europe, Middle-East and Africa Headquarters
Tel: +49 898 780 672 80
India Headquarters
Tel: +91 80 28411633
Lineage Power reserves the right to make changes to the product(s) or information contained herein without notice. No liability is assumed as a result of their use or
application. No rights under any patent accompany the sale of any such product(s) or information.
Lineage Power DC-DC products are protected under various patents. Information on these patents is available at
www.lineagepower.com/patents
.
© 2009 Lineage Power Corporation, (Plano, Texas) All International Rights Reserved.
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 1. Device Codes
Product Codes
Input Voltage
Output
Voltage
Output
Current
On/Off
Logic
Connector
Type
Comcodes
EHW015A0A1
48V (36-75Vdc)
5.0V
15A
Negative
Through hole
CC109150587
EHW015A0A41Z
48V (36-75Vdc)
5.0V
15A
Negative
Through hole
CC109141818
EHW015A0A41-HZ
48V (36-75Vdc)
5.0V
15A
Negative
Through hole
CC109146387
EHW015A0A41-SZ
48V (36-75Vdc)
5.0V
15A
Negative
Surface mount
CC109146395
Table 2. Device Coding Scheme and Options
Characteristic
Character and Position Definition
Form Factor
E
E = Eighth Brick
Family Designator
H
Input Voltage
W
W = Wide Input Voltage Range, 36V -75V
Output Current
015A0
015A0 =
0
15.0 Amps Rated Output Current
Ra
ti
n
g
s
Output Voltage
A
A = 5.0 Vout Nominal
Omit = No Pin Trim
6
6 = Pin Length: 3.68 mm ± 0.25mm , (0.145 in. ± 0.010 in.)
Pin Length
8
8 = Pin Length: 2.79 mm ± 0.25mm , (0.110 in. ± 0.010 in.)
Action following
Omit = Latching Mode
Protective Shutdown
4
4 = Auto-restart following shutdown (Overcurrent/Overvoltage)
Omit = Positive Logic
On/Off logic
1
1 = Negative Logic
-
Customer Specific
XY
XY = Customer Specific Modified Code, Omit for Standard Code
Omit = Standard open Frame Module
H
H = Heat plate (not available with –S option)
Mechanical Features
S
S = Surface mount connections
Omit = RoHS 5/6, Lead Based Solder Used
Op
ti
o
n
s
RoHS
Z Z = RoHS 6/6 Compliant, Lead free
