Altera Power Requirement by Part Number
Stratix®, Cyclone®, MAX®, Arria™ are registered trademarks of the Altera® Corporation.
Always refer to manufacturer’s specification for correct and up-to-date power information.
Arria™V GX, GT -
Core Voltage: Module Output 1.1V to 3.3V
Input V 0 to 2 Amp 0 to 3 Amp 3 to 6 Amp 6 to 12 Amp 12 to 20 Amp 20 to 30 Amps 30 to 40 Amps (2Vo max) 40 to 50A(2Vo max)
3-14/14.4V APXS002A0X-SRZ PDT/PVX003A0X3-SRZ PDT/PVX006A0X3-SRZ PDT/PVX012A0X3-SRZ UDT/UVT020A0X3-SRZ
4.5-14/14.4V MDT/MVT040A0X3-SRZ* APTS050A0X3-SRPHZ* 1
6-14V APTS030A0X3-SRPHZ3
Arria™V GX, GT -
I/O Voltage: Module Output 1.1 to 2.5V
Input V 0 to 2 Amp 0 to 3 Amp 3 to 6 Amp 6 to 12 Amp 12 to 20 Amp 20 to 30 Amps 30 to 40 Amps (2Vo max) 40 to 50A(2Vo max)
3-14/14.4V APXS002A0X-SRZ PDT/PVX003A0X3-SRZ PDT/PVX006A0X3-SRZ PDT/PVX012A0X3-SRZ UDT/UVT020A0X3-SRZ
4.5-14/14.4V MDT/MVT040A0X3-SRZ* APTS050A0X3-SRPHZ* 1
6-14V APTS030A0X3-SRPHZ3
Arria™ II GX -
Core Voltage: Module Output 0.9V to 3.3V
Input V 0 to 2 Amp 0 to 3 Amp 3 to 6 Amp 6 to 12 Amp 12 to 20 Amp 20 to 30 Amps 30 to 40 Amps (2Vo max) 40 to 50A(2Vo max)
3-14/14.4V APXS002A0X-SRZ PDT/PVX003A0X3-SRZ PDT/PVX006A0X3-SRZ PDT/PVX012A0X3-SRZ UDT/UVT020A0X3-SRZ
4.5-14/14.4V MDT/MVT040A0X3-SRZ* APTS050A0X3-SRPHZ* 1
6-14V APTS030A0X3-SRPHZ3
Arria™ II GX -
Core Voltage: Module Output 0.6V to 2.5V
Input V 0 to 2 Amp 0 to 3 Amp 3 to 6 Amp 6 to 12 Amp 12 to 20 Amp 20 to 30 Amps 30 to 40 Amps (2Vo max) 40 to 50A(2Vo max)
3-14/14.4V APXS002A0X-SRZ PDT/PVX003A0X3-SRZ PDT/PVX006A0X3-SRZ PDT/PVX012A0X3-SRZ UDT/UVT020A0X3-SRZ
4.5-14/14.4V MDT/MVT040A0X3-SRZ* APTS050A0X3-SRPHZ* 1
6-14V APTS030A0X3-SRPHZ3
MAX ® V Series -
System and I/O Voltage: Module Output 1.2V to 4.0V
Input V 0 to 2 Amp 0 to 3 Amp 3 to 6 Amp 6 to 12 Amp 12 to 20 Amp 20 to 30 Amps 30 to 40 Amps (2Vo max) 40 to 50A(2Vo max)
3-14/14.4V APXS002A0X-SRZ PDT/PVX003A0X3-SRZ PDT/PVX006A0X3-SRZ PDT/PVX012A0X3-SRZ UDT/UVT020A0X3-SRZ
4.5-14/14.4V MDT/MVT040A0X3-SRZ* APTS050A0X3-SRPHZ* 1
6-14V APTS030A0X3-SRPHZ3
Cyclone ® IV E, GX -
Core Voltage: Module Output 1.2V to 3.3V
Input V 0 to 2 Amp 0 to 3 Amp 3 to 6 Amp 6 to 12 Amp 12 to 20 Amp 20 to 30 Amps 30 to 40 Amps (2Vo max) 40 to 50A(2Vo max)
3-14/14.4V APXS002A0X-SRZ PDT/PVX003A0X3-SRZ PDT/PVX006A0X3-SRZ PDT/PVX012A0X3-SRZ UDT/UVT020A0X3-SRZ
4.5-14/14.4V MDT/MVT040A0X3-SRZ* APTS050A0X3-SRPHZ* 1
6-14V APTS030A0X3-SRPHZ3
Cyclone ® IV E, GX -
I/O Voltage: Module Output 1.0V to 3.3V
Input V 0 to 2 Amp 0 to 3 Amp 3 to 6 Amp 6 to 12 Amp 12 to 20 Amp 20 to 30 Amps 30 to 40 Amps (2Vo max) 40 to 50A(2Vo max)
3-14/14.4V APXS002A0X-SRZ PDT/PVX003A0X3-SRZ PDT/PVX006A0X3-SRZ PDT/PVX012A0X3-SRZ UDT/UVT020A0X3-SRZ
4.5-14/14.4V MDT/MVT040A0X3-SRZ* APTS050A0X3-SRPHZ* 1
6-14V APTS030A0X3-SRPHZ3
Notes: * These module can only deliver a max of 2Vout
1. Output currents above 50A are also achieved by paralleling multiple APTS050 devices. See specification for details.
All parts are non-isolated buck regulators. As such, Vin must exceed programmed Vout. See individual specifications for details.
