Data Sheet
September 10, 2013

Austin Superlynx

II SMT Non-isolated Power Modules:

2.4 – 5.5Vdc input; 0.75Vdc to 3.63Vdc Output; 16A output current

LINEAGE

POWER

Document No: DS03-109 ver. 1.03

PDF name: superlynx_II_smt_ds.pdf

Ordering Information

Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 2. Device Codes

-Z refers to RoHS compliant versions

Input

Voltage

Output

Voltage

Output

Current

Efficiency

3.3V @ 16A

Connector

Type

Product codes

Comcodes

2.4 – 5.5Vdc 0.75 – 3.63Vdc

16A

95.0%

SMT

ATH016A0X3-SR

108987546

2.4 – 5.5Vdc 0.75 – 3.63Vdc

16A

95.0% SMT

ATH016A0X3-SRZ

CC109104551

2.4 – 5.5Vdc 0.75 – 3.63Vdc

16A

95.0%

SMT

ATH016A0X43-SR

108988465

2.4 – 5.5Vdc 0.75 – 3.63Vdc

16A

95.0%

SMT

ATH016A0X43-SRZ

108996823
