DEH40156 Rev.No.01 1
g
A-Series
®
II Panelboards
AD/AE/AQ Type P & N Power Panel
FB Three-Phase Circuit Breaker Kits
Introduction
These instructions describe the installation of FB three-phase circuit breaker kit into an
A-Series
®
II panelboard. These kits are for use in panelboards ordered with Un-Specified
Space.
The catalog number for six-pole FB breaker kit is ASPP6FB6D.
Parts List for ASPP6FB6D Table 1
ITEM # DESCRIPTION PART # QTY
1 BRANCH BASE FOR B PHASE 139C5702BSEG1 1
2 BRANCH BASE FOR A PHASE 139C5702ASEG1 1
3 BRANCH BASE FOR C PHASE 139C5702CSEG1 1
4 (SPOOL) 10093207P2 6
5 (SCREW-SPOOL) 10093208P2 6
6 (WASHER-SPOOL) 75A105503P111 6
7 (SCREW-BUS) 315A7034P8 6
8 3P BRACKET 139C5700P86 2
9 SCREW, BKT TO RAIL N667P16008B6 8
10 SCREW, C/B TO BKT N80P15046B6 4
11 FILLER PLATE, SE/TED/FB 139C5503P77 1
12 SCREWS, #10-32 X 3/8 N722P16006B6 4
13 NUT N210P16B6 6
14 CUP WASHER, 254V644P1 4
Installation
WARNING: Before attempting to install one of these kits, remove all power from the
panelboard.
Use the following procedure to install a FB circuit breaker kit. Call-out numbers in the
illustrations and numbers in brackets in the text refer to Item Numbers in Table 1.
Installation of a six-pole kit is illustrated in Figure 1 or Figure 2.
1. Remove the interior assembly from its packaging and verify that all parts are
present, as given in the parts list.
2. Remove the 8 screws (600A and 800A panels) securing the dead front to
panelboard interior. Lift off the dead front and place it and the screws aside.
