GE Industrial Solutions EntelliGuard E Network Interlock for 3200-5000 Ampere User Manual
Page 4
Figure 8. Wire routing from the Network Interlock to the secondary disconnect
Figure 9. Microswitch terminals.
9
8
7
6
5
4
3
2
1
18 17 16 15 14 13 12 11 10
27 26 25 24 23 22 21 20 19
36 35 34 33 32 31 30 29 28
Figure 10. Terminal numbering scheme of the secondary
disconnect as seen from the front of the circuit breaker.
NC
COM
NO
