GE Industrial Solutions Austin Lynx II SMT - Manual (Page 21)

Data Sheet
September 10, 2013 Austin Lynx TM II SMT Non-isolated Power Modules:
2.4 – 5.5Vdc input; 0.75Vdc to 3.63Vdc Output; 10A output current
LINEAGE POWER 21
Document No: DS03-105 ver. 1.05
PDF name: lynx_II_smt_ds.pdf
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 2. Device Codes
Device Code
Input
Voltage
Range
Output
Voltage
Output
Current
Efficiency
3.3V@ 10A
On/Off
Logic
Connector
Type
Comcodes
ATH010A0X3-SR 2.4 – 5.5Vdc 0.75 – 3.63Vdc 10 A 95% Negative SMT 108987520
ATH010A0X3-SRZ 2.4 – 5.5Vdc 0.75 – 3.63Vdc 10 A 95% Negative SMT CC109104543
ATH010A0X43-SR 2.4 – 5.5Vdc 0.75 – 3.63Vdc 10 A 95% Positive SMT 108988333
ATH010A0X43-SRZ 2.4 – 5.5Vdc 0.75 – 3.63Vdc 10 A 95% Positive SMT 108996823
-Z refers to RoHS compliant codes
World Wide Headquarters
Lineage Power Corporation
601 Shiloh Road, Plano, TX 75074, USA
+1-800-526-7819
(Outside U.S.A.: +1-972-244-9428)
www.lineagepower.com
e-mail: [email protected]
Asia-Pacific Headquarters
Tel: +65 6593 7211
Europe, Middle-East and Africa Headquarters
Tel: +49 898 780 672 80
India Headquarters
Tel: +91 80 28411633
Lineage Power reserves the right to make changes to the product(s) or information contained herein without notice. No liability is assumed as a result of their use or
application. No rights under any patent accompany the sale of any such product(s) or information.
Lineage Power DC-DC products are protected under various patents. Information on these patents is available at www.lineagepower.com/patents .
© 2009 Lineage Power Corporation, (Plano, Texas) All International Rights Reserved.
