2 Finger Clusters (Assemblies) Accessory Manual DEH-41533 02/12
Related Publications
Publication Publication Number
Brochure DEA-532
Snapshot DEE-543
Installation Manual AKD8 DEH-41549
Installation Manual AKD6 DEH-41548
Installation Manual AKD5 DEH-41547
Accessory: Door Interlock (Door Interlock Kit) DEH-41529
Accessory Retrofill Doors Assembly DEH-41563
Accessory: Position Switch Plate & Position Switch Assembly & Wiring
(Position Switch Kit) DEH-41530
Accessory: Neutral Rogowski CT Disconnect (Neutral Assemblies) DEH-41531
Accessory: Programmer Disconnects DEH-41532
Accessory: Finger Clusters (Cluster Assemblies) DEH-41533
Accessory: Secondary Disconnects DEH-41534
FAQ DEQ-171
Application Guide DET-753
Guideform Spec DET-754
Spare/Renewal Parts Guide DET-755
Estimated Time to Complete Tasks
It takes about 20 minutes to install or replace the assembly.
WARNING: Improper Installation,
Operation, and Maintenance
• Ensure only qualified personnel install,
operate, service, and maintain all
electrical equipment.
• Do not adjust or install the cluster
fingers when the breaker is mounted
on the compartment rails or partly
inserted into the compartment.
• It should be ensured that the breaker has
been extracted from the compartment and
placed on a level table/floor before any
replacement or re-installation is
conducted.
• Failure to comply with these instructions
could result in death or serious injury.
• Ensure only qualified personnel install, operate, service, and maintain all electrical
equipment.
