October 2, 2009 Austin MicroLynx TM II SIP Non-isolated Power Modules:
2.4 – 5.5Vdc input; 0.75Vdc to 3.63Vdc Output; 6A output current
LINEAGE POWER 19
Document No: DS04-024 ver. 1.23
PDF name: microlynx_II_sip_ds.pdf
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 2. Device Codes
Device Code
Input
Voltage
Output
Voltage
Output
Current
Efficiency
3.3V@ 6A
Connector
Type
Comcodes
ATH006A0X 2.4 – 5.5Vdc 0.75 – 3.63Vdc 6 A 96.0% SIP 108989018
ATH006A0XZ 2.4 – 5.5Vdc 0.75 – 3.63Vdc 6 A 96.0% SIP CC109104717
ATH006A0X4 2.4 – 5.5Vdc 0.75 – 3.63Vdc 6 A 96.0% SIP 108989026
ATH006A0X4Z 2.4 – 5.5Vdc 0.75 – 3.63Vdc 6 A 96.0% SIP CC109104725
-Z refers to RoHS-compliant versions.
