October 2, 2009 Austin Superlynx TM II SIP Non-isolated Power Modules:
2.4 – 5.5Vdc input; 0.75Vdc to 3.3Vdc Output; 16A output current
LINEAGE POWER 19
Document No: DS04-020 ver. 1.22
PDF name: superlynx_II_sip_ds.pdf
Ordering Information
Please contact your Lineage Power Sales Representative for pricing, availability and optional features.
Table 2. Device Codes
Product codes Input Voltage Output Voltage
Output
Current
Efficiency
3.3V @ 16A
Connector
Type
Comcodes
ATH016A0X3 2.4 – 5.5Vdc 0.75 – 3.3Vdc 16A 95.0% SIP 108989117
ATH016A0X3Z 2.4 – 5.5Vdc 0.75 – 3.3Vdc 16A 95.0%
SIP CC109104758
ATH016A0X43 2.4 – 5.5Vdc 0.75 – 3.3Vdc 16A 95.0%
SIP 108989125
ATH016A0X43Z 2.4 – 5.5Vdc 0.75 – 3.3Vdc 16A 95.0% SIP CC109104766
-Z refers to RoHS-compliant versions.
