INTRODUCTION
GE Conversion Kits are designed for upgrading existing
ITE®
low-voltage power circuit breakers, rather than
replacing the entire breaker. The Conversion Kits include
MicroVersaTrip Plus™ or MicroVersaTrip PM™ Trip
Units, the latest technological advance in GE trip
systems.
MicroVersaTrip Plus and MicroVersaTrip PM Conversion
Kits are designed and tested to conform to ANSI
Standard C37.59, allowing the retrofitter to properly
install the kit and acceptance test the breaker.
This publication covers installation of MicroVersaTrip
Plus and MicroVersaTrip PM Conversion Kits on ITE®
KD3000 and KE4000 low-voltage power circuit breakers.
Each Conversion Kit contains all the components needed
to convert from the existing trip system.
g
MicroVersaTrip Plus™ and MicroVersaTrip
PM™ Conversion Kits
for ITE
®
KD3000 and KE4000
Low-Voltage Power Circuit Breakers
DEH–40019 Installation Instructions
