5.3 Electrical data for the filaments
The electrode or filament is an extremely important component of a fluorescent lamp.
To operate the lamp at its optimum it is essential for the filament to be maintained within a particular
temperature range. To ensure that this is the case even if control gear is operated with lamps from
different manufacturers, the filament data are standardised.
The filament of a compact fluorescent lamp is defined such that the warm resistance RT specified in
the following table is in equilibrium when the specified test current flows through the filament. The
cold resistance is not standardised and is shown here for the purposes of completeness only.
Lamp
Test current
IT
mA
Warm resistance
RT at IT
Cold resistance
R0 measured at the
pins
OSRAM DULUX ® S/E 7 W 130 50±12.5 11.1
OSRAM DULUX ® S/E 9 W 130 50±12.5 11.1
OSRAM DULUX ® S/E 11 W 130 50±12.5 11.1
OSRAM DULUX ® D/E 10 W 140 50±12.5 11.1
OSRAM DULUX ® D/E 13 W 140 50±12.5 11.1
OSRAM DULUX ® D/E 18 W (XT) 190 26±6.5 6.2
OSRAM DULUX ® D/E 26 W (XT) 310 13±3.25 3.3
OSRAM DULUX ® T/E 13 W 140 50±12.5 11.1
OSRAM DULUX ® T/E 18 W 190 26±6.5 6.2
OSRAM DULUX ® T/E 26 W
1)
310 13±3.25 3.3
OSRAM DULUX ® T/E 32 W
1)
(XT) 310 13±3.25 3.3
OSRAM DULUX ® T/E 42 W
1)
(XT) 310 13±3.25 3.3
OSRAM DULUX ® T/E 14W HE 120 50±12.5 11.1
OSRAM DULUX ® T/E 14W HE 120 50±12.5 11.1
OSRAM DULUX ® T/E 17W HE 120 50±12.5 11.1
OSRAM DULUX ® L 18 W (XT, SP) 340 12±3.0 3.1
OSRAM DULUX ® L 24 W (XT, SP) 340 12±3.0 3.1
OSRAM DULUX ® L 36 W (XT, SP) 385 11±2.75 2.9
OSRAM DULUX ® L 40 W
1)
340 12±3.0 3.1
OSRAM DULUX ® L 55 W
1)
(XT) 500 8±2.0 2.3
OSRAM DULUX ® L 80 W
1)
530 8±2.0 2.1
OSRAM DULUX ® L 16 W HE 160 40 ± 10.0 8,4
OSRAM DULUX ® L 22 W HE 160 40 ± 10.0 8,4
OSRAM DULUX ® L 26 W HE 160 40 ± 10.0 8,4
OSRAM DULUX ® L 28 W HE 160 40 ± 10.0 8,4
OSRAM DULUX ® F 18 W 340 12±3.0 3.1
OSRAM DULUX ® F 24 W 340 12±3.0 3.1
OSRAM DULUX ® F 36 W 385 11±2.75 2.9
CFL SQUARE ® 16W 130 64±16.0 13,5
CFL SQUARE ® 28W 270 17.5±4.4 3,7
CFL SQUARE ® 38W 420 9±2.25 1,9
1) Also for DULUX CONSTANT
2) Guide value
