54
Figure 6-8 Execute ZMODEM
Figure 6-9 Select firmware to upgrade
Select firmware file to upgrade, and firmware upgrade process starts.
Figure 6-10 firmware upgrade process window
6.7 Ping
With this menu, you can test to see if another network device still exists by using the ping function.
Usage of ‘ping’ is as follows.
-----------------------------------------------------------------------------
System administration
-----------------------------------------------------------------------------
1. Device name : LS110
2. Username : root
3. Password : root
4. Factory reset
5. Factory reset without IP settings
6. Firmware upgrade
7. Ping
8. User connection status
9. Telnet configuration enable/disable : Enable
Back, Refresh
---> 7
Enter IP Address or Hostname to ping : 192.168.23.1
to 192.168.23.1 pinging 4 times..
Receive time = 1ms Sequence num = 0
Receive time = 1ms Sequence num = 1
Receive time = 1ms Sequence num = 2
Receive time = 1ms Sequence num = 3
Figure 6-11 ping screen
