29
-------------------------------------------------------------------------------
Welcome to LS110 Configuration Page
Serial No. : LS
MAC Address : 00:01:95:FF:DC:A9
F/W REV. : v0.4.8
IP Mode : Static IP IP Address : 192.168.23.12
-------------------------------------------------------------------------------
Console#1 (Serial) : Available
Console#2 (Telnet) : Available
Console#3 (Telnet) : Connected
-------------------------------------------------------------------------------
1. IP configuration
2. Serial port configuration
3. System information
4. System administration
5. Save changes
6. Exit without reboot
7. Save and reboot
Back, Refresh
---> 2
-------------------------------------------------------------------------------
Serial port configuration
-------------------------------------------------------------------------------
1. Baud rate : 9600
2. Data bits : 8
3. Parity : None
4. Stop bit(s) : 1
5. Flow control : Hardware
6. Inter-character timeout : 0
7. Host mode : Telnet Server
8. Local port : 6001
9. Inactivity timeout : 0
10. DTR behavior : Always HIGH
11. DSR behavior : None
12. Allowed IP : 0.0.0.0
13. Allowed subnet : 0.0.0.0
Back, Refresh
---> 8
Enter local port number
--->
Figure 4-2 Changing Local TCP Port number
4.1.3 TCP Client Mode Operations
The LS110 acts as a TCP client, and the default TCP state is [Closed] in this mode. The remote host
will be either Ethernet-Serial communication devices acting as a TCP server or a socket program
acting as a TCP server running on users’ PC.
1) Typical State Transition
[Closed] --> [Sync-Sent] --> [Established] --> [Data] --> [Closed]
At start-up, an initial TCP state is [Closed]. If there is any incoming data through the serial port, the
LS110 will try to connect to a user-defined remote host. Then, the state will be changed to [Sync-Sent],
