4.2.2 Data Bits, Stop Bit(s), Parity
The factory default setting of data bits, stop bits and parity are 8, 1 and None. They can be changed
using each menu such as ‘Data bits’, ’Stop bit(s)’, and ’Parity’.
-------------------------------------------------------------------------------
Serial port configuration
-------------------------------------------------------------------------------
1. Baud rate : 9600
2. Data bits : 8
3. Parity : None
4. Stop bit(s) : 1
5. Flow control : Hardware
6. Inter-character timeout : 0
7. Host mode : TCP Client
8. Destination IP : 192.168.23.30
9. Destination port : 7001
10. Inactivity timeout : 0
11. Cyclic connection : 0
12. DTR behavior : Always HIGH
13. DSR behavior : None
14. Allowed IP : 0.0.0.0
15. Allowed subnet : 0.0.0.0
---> 2
Select data bits (1 = 7 Bits, 2 = 8 Bits)
--->2
Figure 4-9 Set up the Data bits
-------------------------------------------------------------------------------
Serial port configuration
-------------------------------------------------------------------------------
1. Baud rate : 9600
2. Data bits : 8
3. Parity : None
4. Stop bit(s) : 1
5. Flow control : Hardware
6. Inter-character timeout : 0
7. Host mode : TCP Client
8. Destination IP : 192.168.23.30
9. Destination port : 7001
10. Inactivity timeout : 0
11. Cyclic connection : 0
12. DTR behavior : Always HIGH
13. DSR behavior : None
14. Allowed IP : 0.0.0.0
15. Allowed subnet : 0.0.0.0
---> 4
Select stop bit(s) (1 = 1 Bit , 2 = 2 Bits)
---> 1
Figure 4-10 Set up Stop bit(s)
