SENA LS110 - Manual (Page 53)

53
6.6 Firmware Upgrade
With this menu, you can upgrade the firmware of the LS110. Usage of ‘Firmware upgrade’ is as
follows.
Selecting ‘Firmware upgrade’ in the menu, then wait until following message appears.
-----------------------------------------------------------------------------
System administration
-----------------------------------------------------------------------------
1. Device name : LS110
2. Username : root
3. Password : root
4. Factory reset
5. Factory reset without IP settings
6. Firmware upgrade
7. Ping
8. User connection status
9. Telnet configuration enable/disable : Enable
Back, Refresh
---> 6
Preparing for firmware upgrade. Wait a moment...
Transfer firmware by zmodem using your terminal application.
**B01ff000005b157
Figure 6-7 Firmware upgrade Screen
Execute ZMODEM and select firmware file to upgrade.
